Harley Davidson - STAGE TWO KIT

from $3,254.35

Harley Davidson Intermediate Level Audio Upgrade Kit

4 speaker system

Description

As a Harley Davidson owner, you understand the importance of having a powerful and exhilarating ride. Your motorcycle isn't just a means of transportation, it's an extension of your personality and a symbol of your love for the open road.

When you're cruising down the highway, wind rushing past you, there's nothing quite like the feeling of being one with your bike. But what about the sound? A Harley Davidson is already a loud machine, but that doesn't mean you can't enhance the audio experience. Upgrading your audio system can provide you with an even more immersive and satisfying ride.

However, despite buying a premium audio system with your bike, you still cannot hear it on the open road. Frustration sets in…

With our Harley Audio Upgrade kits, you can blast your favorite tunes and hear them with clarity and depth. You can create a soundtrack for your ride that matches your mood and enhances your experience. Plus you can even hear your music over the roar of your engine!

And let's not forget about the social aspect. As a Harley Davidson owner, you're part of a tight-knit community of riders. Upgrading your audio system can also make you the life of the party, whether it's at a rally, a meet-up, or just hanging out with your fellow riders

Don't settle for a subpar audio experience, upgrade your system and take your ride to the next level.

Ground-Zero-Audio and SounDigital are a potent combination in the world of aftermarket motorbike and ATV audio, and when combined with the know-how here at Old School Car Audio, our bespoke systems hit harder, offer noticeably more crisp and clear sound reproduction, and able to achieve more mid-bass than other aftermarket systems available.

STAGE TWO (Intermediate Level) fits your 2014+ or newer Harley Davidson touring motorcycle.

STAGE TWO includes:

  • 1 set of Ground-Zero-Audio weather resistant GZCF 6.5SPL 6.5” 2-way coaxial speakers for front fairing

  • 1 set of Ground-Zero-Audio weather resistant GZCF 69SPL 6 x 9” 2-way coaxial speakers for Saddle bag lids

  • 1 SounDigital 800.4 EVOX 4-channel amplifier

  • 1 Oxygen Free Copper (OFC) braided power/ground/speaker fused wiring kit

  • Mini 8-channel Digital Signal Processor (DSP) from HKI

  • 3 Stinger 4000 series 2-channel 0.5ft RCA lead

  • Saddle bag wiring kit

  • 1 Saddle bag lid-kit complete (Vivid Black only) or Saddle bag lid cut-in kit (grills and speaker mounts only)

  • 1 line-out converter for OEM speaker outputs to RCA line-level inputs to Amplifier

  • Stinger Roadkill Acoustic treatment kit (Sound Damping) for speaker pods, inner fairing, and bag lids

  • Optional upgrades listed below

Specifications / Information:

  • GZCF6.5SPL 16.5 cm / 6.5" 2-way coaxial speaker 100 / 250 Watt RMS/max, Frequency range 50 Hz - 20 kHz

  • GZCF69SPL 6 x 9" 2-way coaxial speaker 150 / 300 Watt RMS/max, Frequency range 50 Hz - 20 kHz

  • SounDigital 800.4 EVOX 4-channel high power amplifier, Power @ 14.4V @ 4Ω: 4 X 147 WRMS

  • 6 foot length of red and black T-Spec OFC power and ground wire with a T-Spec V8-MANL fuse holder and 60 amp fuse protected by a black nylon braid

  • Two x 4 foot pieces of 16 gauge OFC speaker wire protected by black nylon mesh makes upgrading the factory speaker wires or adding new speakers a smart choice

  • Even for those upgrading the Harmon Kardon system, we supply two 47-ohm 1/2 watt resistors to keep the factory radio outputs active

  • All necessary installation hardware is included along with a 4" x 6" hook and loop mounting pad to hold the amplifier securely in place

  • Stinger 4000 Series directional RCA lead, twisted pair construction with small fitment heads offer improved sound quality, noise rejection and easy installation

  • Line-out Converter, convert speaker level outputs from OEM headunit to RCA line-level inputs to amplifier and/or DSP

Optional Upgrades:

  • Upgrade to a SounDigital 800.4 EVOPS (Power Sports) 4-channel amplifier (IP64 Weather resistant for bikes with vented front fairings) 2 x 446 Watts RMS. This is our preferred and highly-recommended amplifier option

  • Upgrade to the GZCF 165Neo-Pro (Red basket) speakers for the front fairing

  • Have the team at old School Car Audio custom pre-wire your entire system to make installation simple. No worrying about which wire goes where, complete custom built harness connected to all components and shipped complete!

Other:

  • All systems require a flash tune of your Harley Davidson ECU to change the source radio output voltage and modify the internal EQ curve to the appropriate settings before installation. This is available as an optional extra from Old School Car Audio here in Perth, or your experienced Harley Dealer.

  • Warning - Amplifier gain settings need to be professionally set to protect speakers at higher power ratings.

  • All DSP settings need to be measured and setup utilising a professional Real-Time Analyser (RTA). This is available here at Old School Car Audio in Perth, for the ultimate sound experience on your Harley.

  • Modifications to speaker pods and saddle bag speaker adapters are required to fit the GZCF 6.5 and 69SPL speakers.

  • Saddle bag cut-in kits require careful cutting of your existing saddle bag.

  • Contact us for more specific information on your motorbike and a customised quotation.

Select Package and Options:
Quantity:
Add To Cart
