Ground Zero GZHA MINI FIVE DSP Amplifier
High efficient 5-channel class D amplifier with built-in 7-channel DSP
Description
Compact in size, colossal in capability—the GZHA MINI FIVE-DSP from Ground Zero’s Hydrogen Series is the ultimate all-in-one amplifier solution for clean, customizable, and high-performance car audio. This 5-channel Class D amplifier combines brute power with an advanced 8-channel DSP, giving you total control over your entire soundstage.
Delivering up to 600W RMS on the subwoofer channel (1Ω stable) and 4 x 125W RMS for mids and highs, it’s designed to push complex multi-speaker systems with clarity and impact. With PC and app-based tuning, real-time adjustments, 8x 10-band parametric EQ, time alignment, phase correction, and adjustable crossovers (HPF/LPF/BPF), this amp gives audiophiles, tuners, and pros the tools to dial in the perfect system.
Its sleek chassis hides enormous flexibility, supporting high- and low-level inputs, auto turn-on, 6 preset slots, and optional accessories like the GZDSP REM wired remote or BTS wireless streaming adapter.
Whether you’re building a competition-grade setup or a stealthy SQ daily driver, the GZHA MINI FIVE-DSP is the heartbeat of your system—powerful, precise, and uncompromising.
Specifications / Information:
Compact sized 5-channel amplifier with DSP
7-channel DSP
Class D technology
1 ohm stable (subwoofer channel)
Parametric equalizer for each channel (10 bands/channel)
Time alignment (0-8 ms / 0-272 cm / 0-107”) for each channel
Adjustable crossover (HPF / LPF / BPF from 20 Hz to 20 kHz)
High-level input with auto-on function
Remote and BT stick available separately
Output Power (@ 4Ω): 4x 75 + 190 Watts RMS
Output Power (@ 2Ω): 4x 125 + 320 Watts RMS
Output Power (@ 1Ω): 1 x 500 W RMS (subwoofer channel)
Max Output Power (CEA-2006A / 10%THD+N): 1200 Watts
Frequency Response 20 Hz – 20 kHz
HPF / LPF / BPF / Bass Boost / Phase Switch: DSP
High-Level Input / Auto-on
Dimensions (W x L x H) 135 x 322 x 52 mm
